Scaffolding screw jack is a standalone steel structural component applied to building temporary support and formwork shoring works, assembled by threaded spindle, adjusting wing nut, base plate or U‑shaped head. Each constituent part bears separate mechanical functions, and the whole unit can complete height adjustment and load‑bearing tasks independently without relying on other scaffolding hardware. The raw material is mainly carbon structural steel, and spindles are divided into solid steel bar and hollow seamless steel pipe. Solid spindle delivers superior compression resistance and bending resistance, suitable for heavy‑load shoring conditions such as high‑rise formwork and large‑span beam support. Hollow spindle reduces dead weight while maintaining basic mechanical performance, matching conventional medium‑load construction scenarios. Thread profiles are mostly produced by cold rolling process, which improves surface hardness of thread teeth and lowers abrasion risk from frequent rotation during repeated turnover cycles. Adjusting nuts are manufactured via forging or casting, and the structural integrity of nuts determines locking reliability under long‑term static vertical load. The flat base plate is welded to spindle bottom, enlarging contact area with supporting surface to disperse concentrated pressure and mitigate subsidence risk on soft ground. The U‑shaped head forms a clamping groove at the top, holding horizontal steel tubes or wooden beams to transfer downward loads from formwork and poured concrete.

Multiple surface anti‑corrosion treatments are available for this component. Hot‑dip galvanizing generates compact zinc‑iron alloy layers covering spindles, thread teeth and welding joints. This protective layer resists erosion from rain, humid air and salt fog, adapting to long‑term outdoor exposure and marine transportation. Electro‑galvanizing creates relatively thin zinc coating, fit for short‑cycle projects with low corrosion exposure. Paint coating tends to peel off under thread friction and mechanical collision, so it is rarely adopted for frequently circulated construction hardware. According to installation position, scaffolding screw jack falls into base jack and U‑head jack. Base jack is fitted under vertical scaffolding standards, bearing overall vertical loads and offsetting foundation height differences. U‑head jack is mounted on top of support uprights to fix horizontal load‑bearing members and undertake formwork system pressure.

Core dimensional parameters define its practical mechanical performance. Spindle outer diameter is a critical indicator, and larger diameter corresponds to higher ultimate compression capacity. Effective adjustment stroke defines allowable height variation range. Excessively exposed threaded segments decrease structural rigidity and raise deformation risk under loaded status. Base plate dimension is selected according to ground bearing capacity; undersized plates will produce excessive ground pressure and trigger local settlement. This component can be compatible with various temporary shoring frameworks, including tube‑and‑coupler scaffolding, ringlock and cuplock systems. Dimensional tolerances shall comply with corresponding international technical specifications to guarantee reliable physical fitting during site assembly.

Prior to field deployment, visual inspection and sampling mechanical tests shall be implemented as separate inspection procedures. Visual examination covers spindle bending, surface cracks, welding discontinuity, thread tooth damage and anti‑corrosion layer peeling. Recycled screw jacks require stricter inspection standards. Even with intact outer appearance, metal fatigue may accumulate after repeated load cycles and cannot be detected merely through surface observation. Sampling compression tests verify ultimate bearing capacity and anti‑deformation property. Units with permanent bending, thread slipping and structural cracks must be sorted out and scrapped and shall not be mixed for construction use. Secondary modification such as cutting, welding or hole‑drilling on finished screw jacks is prohibited. Arbitrary alteration will change original steel section characteristics and weaken overall load‑bearing performance.

Scaffolding screw jack is designed for cyclic reuse. After support frame dismantling, concrete mortar, dust and foreign residues adhering to spindle and thread gaps need thorough cleaning. Impurities trapped inside threads will cause nut jamming and interfere with normal height adjustment and locking in subsequent applications. Finished components shall be stored in dry and ventilated surroundings, sorted by type and specification, avoiding long‑term rain soaking and damp soil contact. Improper site operations include over‑extending threaded segments, placing base plates on uneven ground and applying loads exceeding rated limits. Such improper operations may result in component deformation and abnormal local stress within shoring frames. As an independent steel load‑bearing unit, its structural integrity and mechanical stability directly affect local stress distribution of temporary shoring structures, and serve as essential preconditions for safe operation of scaffolding and formwork support systems.
